Highlights

---

• 5-axis | 5-sided machining up to Ø800mm
• 4-axis machining up to 2000x800mm
• Large range of parts can be covered
• Single and multiple clamping in the vice, on the grid table or the vacuum plate
• Tool magazine with 90 pockets

Raw part sizes

Types	Unit of measurement	Value
5-axis horizontal X/Y/Z	mm	1050/1050/800
5-axis vertical X/Y/Z	mm	1050/300/800
3/4 axis horizontal X/Y/Z	mm	2000/800/800
3/4-axis vertical X/Y/Z	mm	2000/300/800

Exemplary part clamping placements

Works area

Types	Unit of measurement	Value
X-Axis	mm	2000
Y-Axis	mm	800
Z-Axis	mm	850
B-Axis	°	+/- 120
C-Axis	°	360
Workpiece diameter	mm	800
Workpiece height	mm	800

Spindle

---

Types	Unit of measurement	Value
Speed	rpm	20.000
Power	kW	35
Torque	Nm	130
